| สถานที่กำเนิด: | กวางตุ้งจีน |
|---|---|
| ชื่อแบรนด์: | RAYMO |
| หมายเลขรุ่น: | RM-S-AF1S-P19JS-052/DBPU-AF1S-P19KS |
| จำนวนสั่งซื้อขั้นต่ำ: | 1 |
| รูปร่าง: | กลม | จัดอันดับปัจจุบัน: | 3 |
|---|---|---|---|
| วัสดุติดต่อ: | ทองเหลือง | ระดับ IP: | IP68 |
| วัสดุที่อยู่อาศัย: | ทองเหลืองทองเหลืองสีดำ /ธรรมชาติ | เบอร์ติดต่อ.: | 10,12,15,19pins |
| ฉนวน: | กปปส | ประเภทติดต่อ: | ประเภทบัดกรี |
| การผสมพันธุ์สูงสุด: | 5,000 | ช่วงอุณหภูมิ: | -65 ° C, +200 ° C |
| ความชื้น: | สูงถึง 95% ที่ 60 ° C/140F | ความต้านทานการสั่นสะเทือน: | 15 ก. [10 เฮิรตซ์ - 2000 เฮิรตซ์] |
| ความต้านทานแรงกระแทก: | 100 กรัม [6 มิลลิวินาที] | การทดสอบสเปรย์เกลือ: | > 96 ชม. |
| การป้องกัน: | > 75 dB [ที่ 10 MHz],> 40 dB [ที่ 1 GHz] | ||
| เน้น: | IP68 waterproof circular connector,19 pin push pull connector,male female circular connector |
||
| Attribute | Value |
|---|---|
| Shape | ROUND |
| Rated Current | 3 |
| Contact Material | Brass |
| IP Level | IP68 |
| Type | Adapter |
| Application | Audio & Video |
| Gender | Male and female |
| Housing Material | Brass, black/natural chrome-plated brass |
| Shell Style/Model | Push pull connector |
| Certificate | ISO9001/CE/ROHS/REACH |
| Contact No. | 10,12,15,19 pins |
| Insulator | PPS |
| Contact Type | Solder type |
| Cable Assembled | YES |
| Max. Mating | 5000 |
| MOQ | No MOQ limit |
| Characteristic | Value |
|---|---|
| Endurance (shell) | 5000 mating cycles |
| Humidity | Up to 95% at 60°C/140°F |
| Temperature Range | -65°C to +200°C |
| Resistance to Vibrations | 15 g [10 Hz - 2000 Hz] |
| Shock Resistance | 100 g [6 ms] |
| Salt Spray Corrosion Test | >96 hr |
| Climatical Category | 50/175/21 |
| Shielding (min) | >75 dB [at 10 MHz], >40 dB [at 1 GHz] |
| IP Rating | IP68 |
| Certifications | ISO9001/CE/ROSH/SGS |
Automotive, Audio-Video, Aviation, Communications, Industrial Control, Information Systems, Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment, Module Power, Sensor, Sensor Systems Instrumentation, Analysis Application.
As a manufacturer located in Shenzhen, we specialize in manufacturing connectors and cable assemblies, serving more than 150 countries since 2010. Raymo Connectors is committed to working closely with customers to equip their applications with the most appropriate connector and cable systems. Our product range comprises over 3,000 standard items, and we are always prepared to develop customized solutions for specific requests.
Loading Port: Shenzhen, China
Goods can be shipped by air, sea, or other methods. Delivery time depends on order quantity and exact items.
Yes, we specialize in producing circular push pull connectors and cable assemblies since 2010. Our factory is SGS audited and has been working on Alibaba for more than 7 years.
No MOQ limit - small orders are accepted based on customer needs.
Yes, free samples are available. Please contact us for details.
Samples: 1-2 working days; Mass production: 5-10 working days.
100% T/T deposit when customer places order.
Yes, all connectors can work normally after 5000 mating cycles. We test all products before shipping. Warranty does not cover damage due to misuse, unauthorized modifications, or repairs.
