| สถานที่กำเนิด: | กวางตุ้งจีน |
|---|---|
| ชื่อแบรนด์: | RAYMO |
| ได้รับการรับรอง: | CE / RoHS / SGS / ISO9001:2015 |
| Model Number: | RM-S-0F2S-P02JS26Z |
| จำนวนสั่งซื้อขั้นต่ำ: | 1 ชิ้น |
| ราคา: | negotiable |
| รายละเอียดการบรรจุ: | ถุง PE และกล่อง |
| เวลาการส่งมอบ: | 5-8 วันทำการ |
| เงื่อนไขการชำระเงิน: | t/t, l/c |
| สามารถในการผลิต: | 5,000 ชิ้นต่อสัปดาห์ |
| Prct Description:: | S/ SC Cable mount plug | Shell Size:: | 102/0F (103/1F, 1031/AF, 104/2F, 105/3F are available) |
|---|---|---|---|
| Application:: | Medical, Machines, Military, Audio& Video, Automative | Contact No.:: | 2 pins (3, 4, 5, 7, 9 10 pins are available) |
| Insulator:: | PPS / PEEK | Outer Shell Material:: | Brass with chrome plated |
| สี:: | เงิน / ดำ | วัสดุติดต่อ: | ทองเหลืองชุบทอง |
| ประเภทการติดต่อ:: | ประสาน | คะแนน IP:: | IP68 |
| ความอดทน:: | 5,000 รอบ | บริการที่กำหนดเอง:: | เซินเจิ้น |
| เน้น: | waterproof wire connectors,waterproof electrical connectors |
||
S/SC 102 103 1031 104 series circular push pull waterproof connectors are compatible with Fischer's SS/SSC staight plug.
P/N: RM-S-0F2S-P02JS26Z / S 102 A051 - 242
Description: S 102/0F series straight plug, keying code 2, 2pin male contacts, in solder type, PPS insulator, outer shell in black chrome plated brass, cable collet for 2.1-2.6mm cable, nut for fitting a bend relief, black bend relief.
Main features:
| Series | Contact No. with solder & PCB type |
|---|---|
| 102/0F | 2, 3, 4, 5, 7, 9 |
| 103/1F | 2, 3, 4, 5, 6, 7, 8, 10, 12, 14, 16 |
| 1031/AF | 10, 12, 15, 19 |
| 104/2F | 2, 8, 16, 19 |
Photo & Dimensions:
Application:
RAYMO's high quality connectors are found in a variety of challenging applications and environmetns including:
Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor, Sensor Systems Instrumentation, Analysis Application.
SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen, focusing on manufacturing, Creative customer-oriented metal and plastic circular push-pull self-latching connectors and cable assemblies to serve over 75 countries and regions since 2010.
With professional R&D and excellent craftsmanship, our factory has the ability of offering customer with much more precision connectors and cable harness solutions to meet customer's real needs in this fields.
Aimed on offering customer qualified and suitable connectors and cable assemblies, our factory has already designed and developed over 3,000 types of connectors and 1,000 kinds of OEM cable assemblies based on customer's real needs.
RAYMO's high quality connectors are found in a variety of challenging applications and environments including:
Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application.
