| สถานที่กำเนิด: | เซินเจิ้น กวางตุ้ง ประเทศจีน |
|---|---|
| ชื่อแบรนด์: | RAYMO |
| ได้รับการรับรอง: | RoHS, Reach, SGS, ISO:9001-2015 |
| Model Number: | PAG.M0.2GL.AC39A |
| จำนวนสั่งซื้อขั้นต่ำ: | 1 ชิ้น/ชิ้น |
| ราคา: | negotiable |
| รายละเอียดการบรรจุ: | ถุง PE และกล่อง |
| เวลาการส่งมอบ: | 3-5 วันทำการ |
| Payment Terms: | Western Union, T/T , MoneyGram, D/P, D/A, MoneyGram, L/C |
| สามารถในการผลิต: | 5000 ชิ้น/สัปดาห์ |
| Type: | Lemo Redel push-pull connector | Contact no.: | 2-14pins |
|---|---|---|---|
| เพศ: | ตัวเมียเพศชาย | Insulator: | PPS, PEEK |
| การจัดอันดับ IP: | IP50 | Shell Material: | PC, PSU, PEEK |
| Application: | Edan Medical fetal monitor, ECG monitor | Shell colour: | Red, gray, green, black, yellow, white, blue |
| เน้น: | plastic push pull connector,raymo connectors |
||
Medical 1P M14 Circular Plastic Connector, Lemo Redel's wire pleastic connectors PAG.M0.2GL.AC39A
Raymo plastic push pull connectors RM-P series compatible with Lemo REDEL PLASTIC CONNECTORS
|
PARTS No. |
Raymo P/N |
LEMO Redel P/N |
|
RM-PAG-1PC-302-JS39A |
PAG.M0.2GL.AC39A |
|
|
Description |
straight plug with cable collet and alignment key (G=0 degree), multipoles 2 contacts to solder, blue PC outer shell, PPS insulator, collet for 3.2-3.9mm diameter cable |
|
|
Plastic Circular Push Pull connector RM-p series |
|||||||||||||
|
Series |
IP |
Shell Size |
Contacts No. with solder & PCB type |
||||||||||
|
RM-P |
40 |
1P /Redel |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
10 |
12 |
14 |
|
Features |
|
|
1 |
Light weight |
|
2 |
Wide choice of colors for easy identification(Grey,Blue,Yellow,Black,Red,Green) |
|
3 |
Large choice of keying to avoid cross mating(0°,40°,60°,80°,155°,170°) |
|
4 |
Various contact types:solder,print and elbow print 90° |
|
Characteristics |
|
|
Temperature Range |
- 40° C, +110° C |
|
IP Rating |
IP 40 |
|
Endurance(shell) |
1,000 cycles |
|
Color code |
Different color nut for easy Identification |
SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen, focusing on manufacturing Creative customer-oriented metal and plastic circular push-pull self-latching connectors and cable assemblies to serve over 75 countries and regions since 2010. Our prcts got very popular recommendation among our customers.
This vast portfolio enables you to select the ideal connector configuration to suit almost any specific requirement in most markets inclyding medical devices, test and measurement instruments, machinery, audio video broadcast, telecommunications and military
Cable mount plug,RM-P series, Prcts Photo, Shell size and Dimension
Why Choose US?
100% compatible with lemo, , fischer connector
Help you save at least 50% cost
All the prcts we got CE, ROHS, SGS,ISO9000 certificate
Fast delivery: 2-15 working days
Cable assembly offer, help you save prction time
|
2020.11 |
Electronica Munich, Germany |
|
2019 9.24-9.26 |
Testing Expo, Shanghai |
|
2018 11.12-11.15 |
Electronica Munich, Germany |
|
2017 9.11-9.16 |
NAB Show,Netherlands |
|
2016 4.11-4.15 |
HK Fair |
|
2015 10.2-10.7 |
ICEEB, Brasil |
|
2014 10.11-10.15 |
HK Fair |
|
2014 4.11-4.15 |
HK Fair |
If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
